Dimension(Lx W xH)（unloaded）（mm）
|
10545*2496*3450
|
|
Driving Type
|
Right Hand Driving
|
|
Cargo body size (L*W*H, mm)
|
7500*2300*1500mm bottom:10mm,side:8mm
|
|
Cargo Tank length
|
6.2-8m
|
|
Lifting Cylinder
|
China Brand
|
|
Lifting Type
|
Front side Lifting
|
|
Capacity (Load)
|
31 - 40T
|
|
Approaching angle/Departure angle（°）
|
19/20
|
|
Overhang(front/rear) (mm)
|
1500/2095
|
|
Wheel base (mm)
|
1800+3800+1350
|
|
Curb weight(kg)
|
15200
|
|
Persons in cab(persons)
|
2
|
|
Gross vehicle weight(kg)
|
31000
|
|
Max speed（km/h）(km/h)
|
80
|
|
Engine Model
(Steyr technology, made in China)
|
WD615.47 water-cooled，four strokes，6 cylinders in line with water cooling, directly injection
|
|
Fuel type
|
Diesel
|
|
Drive Wheel
|
8X4
|
|
Horse Power, max（kw/rpm）
|
371HP
|
|
Emission
|
EURO II
|
|
Fuel tanker capacity （L）
|
300
|
|
Transmission Model
|
HW19710 10 forwards and 2 reverse
|
|
Steering Model
|
8198 Mechanical transmission with hydraulic assistance Steering gear re-circulating ball type.
|
|
Clutch
|
single disc, dry type, diaphragm spring ;φ430
φ430
|
|
Service brake
|
Dual circuit compressed air brake
|
|
Parking brake
|
spring energy, compressed air operating on rear wheels
|
|
Auxiliary brake
|
The engine exhaust brake （EVB）
|
|
Front axle
|
HF9 Steering with double T-cross section beam
|
|
Rear axle
|
HC16 Casting axle housing, central double reduction with differential locks between axles and wheels
|
|
Color
|
White, Red, Yellow. according to the customer
|
|
Tyre
|
12.00R20
NO.12+1 Pieces
|
|
Electrical system
|
Battery
|
2X12V/180Ah
|
| |
Alternator
|
28V-1500kw
|
| |
Starter
|
7.5Kw/24V
|
