Used HOWO 30 Ton Dump Trucks
- Loading capacity:30-40 TON
- Emission Standard:Euro 2
- Brand Name: SIONTRUK HOWO
- Cargo Tank Dimension:5400x2300x1400mm
- Cargo Tank length:5.3-6.2M
This used 6×4 HOWO 30 ton dump truck is designed for hauling and transporting all kinds of heavy materials over long distances. This used dump truck has been reconditioned with a powerful engine and heavy-duty axles, making it ideal for heavy-duty applications. They are also designed with a high-strength steel frame and a durable tipping bucket that can hold up to 35 tons of material. And the Howo 10 Wheeler Dump Truck is also equipped with advanced safety features, making it a safe and reliable choice for long-distance transportation of heavy materials.
|
SINOTRUK HOWO 6×4 Dump Truck
|
|
General
|
Truck size
|
8150x2500x3170mm
|
|
Dump box dimension
|
5400x2300x1400mm
|
|
Lifting type
|
middle lift
|
|
Dump box steel thickness
|
Floor 8mm, Side 6mm
|
|
Authorized loading capacity
|
25-40T
|
|
Color
|
Red
|
|
Chassis
|
Chassis Model
|
ZZ3257N3647A
|
|
Drive model
|
6x4
|
|
Axles number
|
3
|
|
Wheel base
|
3625+1350
|
|
Rim/Tires
|
12.00R20,11pieces including 1 spare tyre.
|
|
F/R overhang
|
1500/1670
|
|
Approach/Departure
|
19/26
|
|
F/R Leaf spring
|
10/12
|
|
F/R tread
|
1830/1830
|
|
Front axle
|
HF9, 9 tons load capacity
|
|
Rear axle
|
HC16 ,16x2 tons load capacity
|
|
Engine
|
Brand
|
CNHTC brand
|
|
Model
|
WD615.69
|
|
Power
|
336hp
|
|
Displacement
|
9726ml
|
|
Emission standard
|
Euro II
|
|
Rated speed
|
2200rpm
|
|
Max torque
|
1350N.m/1100-1600rpm
|
|
Description
|
Inline six-cylinder, water-cooled, four-stroke, supercharged intercooled, direct injection
|
|
Transmission
|
Model
|
HW19710
|
|
Speed
|
10 forward + 2 rear
|
|
Type
|
MT
|
|
Speed ratio
|
F:14.284/10.623/7.871/5.876/4.375/3.265/2.428/1.799/1.343/1
R:13.913/3.18
|
|
Cabin
|
Cab
|
HW76 standard cab
|
|
Seats
|
2 seats + 1 berth
|
|
Steering
|
ZF hydraulic steering with power assistance
|
|
Air conditioner
|
equipped
|
