Drive Type
|
6x4
|
|
Size
|
Wheelbase (mm)
|
4625+1400
|
| |
Overall size (mm)
|
9770*2496*3170
|
| |
Body (mm)
|
5800*2300*1000
|
|
Driving type
|
Left hand drive (LHD)
|
|
Weight
|
Curb weight
|
12270 kg
|
| |
G.V.W
|
25000 kg
|
| |
Model
|
WD615.47,371hp, Diesel.
|
|
Engine
|
Type
|
Six cylinders inline, water cooling, 4 stroke, supercharge inter cooler
|
| |
Fuel tanker(L)
|
400
|
|
|
Max Power (hp)
|
371hp
|
| |
Rated Power (kw/rpm)
|
276/2200
|
| |
Maximum Torque (Nm)
|
1500N.m
|
| |
Maximum Torque speed
|
1600RPM
|
| |
Compression ratio
|
17.5：117：1
|
| |
Bore X Stroke
|
126x130mm
|
| |
Displacement
|
9.726 L
|
|
Cabin
|
HW76, plat-roof cab, one sleeper (berth), Air-conditioner, MP3, safety belts, curtain.
|
| |
Adjustable steering wheel, air horn, with 4-point support fully floating suspension and
|
| |
shock absorbers.
|
|
Transmission
|
HW15710C, 10 F and 2 R, manual.
|
|
Front Axles
|
HF9,9T
|
|
Rear Axles
|
HC16, 16TX2, drum brake. Speed ratio: 4.8.
|
|
Steering
|
ZF hydraulic steering with power assistance
|
|
Brake system
|
Service brake: dual circuit compressed air brake
|
| |
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
|
| |
Auxiliary brake: engine exhaust brake
|
|
Electric system
|
Operating voltage: 24 V, negative grounded
|
| |
Starter: 24 V, 5.4 Kw
|
| |
Alternator: 3-phase, 28 V, 1500 W
|
| |
Batteries: 2 x 12 V, 165 Ah
|
| |
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
|
|
Tyre
|
12.00R20
|
|
Fuel tank
|
400L volume
|
